Week Content

Week Overview

This week shifts to defensive security automation. You will build Python tools that ingest logs, detect anomalies, and enrich suspicious events with threat intelligence.

• Parse and normalize syslog, JSON, and Windows event logs
• Build baseline metrics and detect deviations
• Automate alerting for failed logins and suspicious activity
• Enrich events with IP reputation and geolocation
• Design a mini-SIEM workflow with summary dashboards

Section 1: Log Formats & Normalization

Why Normalization Matters

Logs come from different sources and formats. Normalization converts them into a consistent schema so alerts, dashboards, and analytics can query reliably.

Common Log Formats

• Syslog: RFC 3164/5424 text format, common for Linux services
• JSON Logs: Structured logs from cloud systems and modern apps
• Windows Event Logs: XML or EVTX data exported from Windows

Syslog Severity Levels

Windows Event ID Quick Reference

• 4624: Successful logon
• 4625: Failed logon (brute force indicator)
• 4688: Process creation (useful for malware hunting)
• 4720: User account creation
• 4726: User account deletion
• 4769: Kerberos service ticket request

Example: Multi-format Normalizer

#!/usr/bin/env python3
"""
Multi-format log normalizer.
Supports syslog, JSON, and Windows Event Log exports (XML).
"""
from __future__ import annotations

import json
import re
import xml.etree.ElementTree as ET
from datetime import datetime
from typing import Dict, Optional

SYSLOG_PATTERN = re.compile(
    r"^(?P<ts>\w{3}\s+\d{1,2}\s+\d{2}:\d{2}:\d{2})\s+"
    r"(?P<host>[\w\.-]+)\s+(?P<app>[\w\-/]+)(?:\[(?P<pid>\d+)\])?:\s+(?P<msg>.*)$"
)


def parse_syslog(line: str) -> Optional[Dict[str, str]]:
    """
    Parse a syslog line into a normalized dict.

    Args:
        line: Raw syslog line

    Returns:
        Normalized dict or None if parsing fails
    """
    match = SYSLOG_PATTERN.match(line.strip())
    if not match:
        return None

    data = match.groupdict()
    try:
        ts = datetime.strptime(data["ts"], "%b %d %H:%M:%S")
    except ValueError:
        ts = datetime.utcnow()

    return {
        "timestamp": ts.isoformat(),
        "source": "syslog",
        "host": data.get("host", "unknown"),
        "app": data.get("app", "unknown"),
        "pid": data.get("pid", "-"),
        "message": data.get("msg", ""),
    }


def parse_json(line: str) -> Optional[Dict[str, str]]:
    """
    Parse JSON log line into a normalized dict.
    """
    try:
        raw = json.loads(line)
    except json.JSONDecodeError:
        return None

    return {
        "timestamp": raw.get("timestamp") or raw.get("@timestamp", ""),
        "source": raw.get("source", "json"),
        "host": raw.get("host", "unknown"),
        "app": raw.get("service", raw.get("app", "unknown")),
        "pid": str(raw.get("pid", "-")),
        "message": raw.get("message", ""),
    }


def parse_windows_event(xml_line: str) -> Optional[Dict[str, str]]:
    """
    Parse Windows Event Log XML export.
    """
    try:
        root = ET.fromstring(xml_line)
    except ET.ParseError:
        return None

    ns = {"ns": "http://schemas.microsoft.com/win/2004/08/events/event"}
    system = root.find("ns:System", ns)
    event_data = root.find("ns:EventData", ns)

    if system is None:
        return None

    ts_node = system.find("ns:TimeCreated", ns)
    provider = system.find("ns:Provider", ns)
    computer = system.find("ns:Computer", ns)

    timestamp = ts_node.get("SystemTime") if ts_node is not None else ""
    provider_name = provider.get("Name") if provider is not None else "Unknown"
    host = computer.text if computer is not None else "unknown"

    message_fields = []
    if event_data is not None:
        for data in event_data.findall("ns:Data", ns):
            field_name = data.get("Name", "field")
            field_val = data.text or ""
            message_fields.append(f"{field_name}={field_val}")

    return {
        "timestamp": timestamp,
        "source": "windows_event",
        "host": host,
        "app": provider_name,
        "pid": "-",
        "message": "; ".join(message_fields),
    }


def normalize_line(line: str) -> Optional[Dict[str, str]]:
    """
    Determine log format and normalize.
    """
    if line.strip().startswith("{"):
        return parse_json(line)
    if line.strip().startswith("<Event"):
        return parse_windows_event(line)
    return parse_syslog(line)


def example() -> None:
    """Example usage for quick validation."""
    syslog_line = "Oct 17 12:10:22 server sshd[1234]: Failed password for root from 10.0.0.5 port 51515"
    json_line = '{"timestamp": "2024-10-17T12:10:22Z", "service": "api", "message": "Login failed", "host": "web1"}'
    print(normalize_line(syslog_line))
    print(normalize_line(json_line))


if __name__ == "__main__":
    example()

Sample Logs for Testing

Oct 17 12:10:22 server sshd[1234]: Failed password for root from 10.0.0.5 port 51515
Oct 17 12:10:25 server sshd[1234]: Failed password for root from 10.0.0.5 port 51516
{"timestamp": "2024-10-17T12:12:10Z", "service": "api", "message": "Invalid token", "host": "edge-1"}
<Event xmlns="http://schemas.microsoft.com/win/2004/08/events/event">
  <System>
    <Provider Name="Microsoft-Windows-Security-Auditing"/>
    <TimeCreated SystemTime="2024-10-17T12:14:01.000Z"/>
    <Computer>WIN-01</Computer>
  </System>
  <EventData>
    <Data Name="TargetUserName">administrator</Data>
    <Data Name="IpAddress">203.0.113.12</Data>
    <Data Name="LogonType">3</Data>
  </EventData>
</Event>

Section 2: Baselines & Anomaly Detection

Baseline vs Deviation

Defensive analytics starts with a baseline. You quantify normal behavior (failed logins per user, ports per host) then flag deviations.

Failed Login Detector with Rolling Stats

#!/usr/bin/env python3
"""
Detect login anomalies using rolling statistics.
"""
from __future__ import annotations

import csv
from datetime import datetime, timedelta
from typing import Dict, List

import pandas as pd


def load_login_events(path: str) -> pd.DataFrame:
    """
    Load normalized login events from CSV.

    CSV must include: timestamp, username, source_ip, outcome
    """
    try:
        df = pd.read_csv(path)
    except FileNotFoundError:
        raise FileNotFoundError(f"Missing log file: {path}")

    df["timestamp"] = pd.to_datetime(df["timestamp"], errors="coerce")
    df = df.dropna(subset=["timestamp"])
    return df


def calculate_baseline(df: pd.DataFrame, window: str = "60min") -> pd.DataFrame:
    """
    Compute rolling baseline for failed logins.
    """
    failures = df[df["outcome"] == "failed"].copy()
    failures = failures.set_index("timestamp")
    failures["count"] = 1

    baseline = failures.groupby("username").resample(window).sum()
    baseline = baseline.reset_index().rename(columns={"count": "failed_count"})
    return baseline


def detect_anomalies(baseline: pd.DataFrame, threshold: int = 8) -> pd.DataFrame:
    """
    Flag buckets exceeding threshold.
    """
    return baseline[baseline["failed_count"] >= threshold]


def summarize(anomalies: pd.DataFrame) -> None:
    """
    Print simple summary of anomalies for analysts.
    """
    if anomalies.empty:
        print("[✓] No anomalies detected")
        return

    print("[!] Anomalous failed login spikes")
    for _, row in anomalies.iterrows():
        print(
            f"User={row['username']}, Window={row['timestamp']}, "
            f"Failures={int(row['failed_count'])}"
        )


if __name__ == "__main__":
    events = load_login_events("./normalized_logins.csv")
    baseline = calculate_baseline(events)
    spikes = detect_anomalies(baseline, threshold=10)
    summarize(spikes)

Z-Score Anomaly Scoring

#!/usr/bin/env python3
"""
Score anomalies using a z-score for each user.
"""
from __future__ import annotations

import pandas as pd
from typing import Tuple


def zscore_anomalies(df: pd.DataFrame, window: str = "30min") -> pd.DataFrame:
    """
    Compute per-user z-scores for failed logins.
    """
    failures = df[df["outcome"] == "failed"].copy()
    failures["timestamp"] = pd.to_datetime(failures["timestamp"], errors="coerce")
    failures = failures.dropna(subset=["timestamp"])
    failures = failures.set_index("timestamp")

    counts = failures.groupby("username").resample(window).size().reset_index(name="failed_count")

    # Compute mean/std per user
    stats = counts.groupby("username")["failed_count"].agg(["mean", "std"]).reset_index()
    merged = counts.merge(stats, on="username", how="left")
    merged["std"] = merged["std"].fillna(1.0)
    merged["zscore"] = (merged["failed_count"] - merged["mean"]) / merged["std"]
    return merged.sort_values("zscore", ascending=False)


if __name__ == "__main__":
    df = pd.read_csv("./normalized_logins.csv")
    scored = zscore_anomalies(df)
    print(scored.head(10))

Sample Normalized CSV

timestamp,host,source,app,message,source_ip,username,outcome
2024-10-17T12:10:22Z,auth-01,syslog,sshd,Failed password for root from 203.0.113.12,203.0.113.12,root,failed
2024-10-17T12:10:24Z,auth-01,syslog,sshd,Failed password for root from 203.0.113.12,203.0.113.12,root,failed
2024-10-17T12:11:10Z,auth-01,syslog,sshd,Accepted password for alice from 198.51.100.40,198.51.100.40,alice,success
2024-10-17T12:12:02Z,auth-01,syslog,sshd,Failed password for admin from 203.0.113.12,203.0.113.12,admin,failed
2024-10-17T12:12:05Z,auth-01,syslog,sshd,Failed password for admin from 203.0.113.12,203.0.113.12,admin,failed
2024-10-17T12:13:10Z,auth-01,syslog,sshd,Accepted password for admin from 203.0.113.12,203.0.113.12,admin,success

Rule Definition (Sigma-like YAML)

title: SSH Brute Force Spike
id: 2e4a8e6b-9a10-4a50-94e6-8b3b4051f2df
status: experimental
description: Detects multiple failed SSH logins from same IP
logsource:
  product: linux
  service: sshd
detection:
  selection:
    message|contains: "Failed password"
  timeframe: 10m
  condition: selection | count(source_ip) > 8
falsepositives:
  - Maintenance scripts
  - Vulnerability scanners in authorized tests
level: high

Enrichment: IP Reputation Cache

#!/usr/bin/env python3
"""
Simple IP reputation cache to reduce API calls.
"""
from __future__ import annotations

import json
import time
from pathlib import Path
from typing import Dict, Optional

CACHE_FILE = Path("./ip_reputation_cache.json")
CACHE_TTL = 3600  # 1 hour


def load_cache() -> Dict[str, Dict[str, str]]:
    """Load cached reputation data from disk."""
    if CACHE_FILE.exists():
        try:
            return json.loads(CACHE_FILE.read_text())
        except json.JSONDecodeError:
            return {}
    return {}


def save_cache(cache: Dict[str, Dict[str, str]]) -> None:
    """Persist cache to disk."""
    CACHE_FILE.write_text(json.dumps(cache, indent=2))


def get_cached_ip(cache: Dict[str, Dict[str, str]], ip: str) -> Optional[Dict[str, str]]:
    """Return cached entry if fresh."""
    entry = cache.get(ip)
    if not entry:
        return None

    if time.time() - entry.get("cached_at", 0) > CACHE_TTL:
        return None
    return entry


def set_cached_ip(cache: Dict[str, Dict[str, str]], ip: str, data: Dict[str, str]) -> None:
    """Store entry with cache timestamp."""
    data["cached_at"] = int(time.time())
    cache[ip] = data

Section 3: Real-Time Monitoring with watchdog

Why Real-Time Matters

Batch analysis is useful for reporting, but defenders often need immediate alerts. A lightweight file watcher can mimic SIEM live pipelines.

Tail-Following Log Stream

#!/usr/bin/env python3
"""
Follow a log file like `tail -f` and emit normalized events.
"""
from __future__ import annotations

import time
from pathlib import Path
from typing import Iterator


def follow(path: Path) -> Iterator[str]:
    """
    Yield new lines appended to a file.
    """
    with path.open("r", encoding="utf-8") as handle:
        handle.seek(0, 2)  # Seek to end
        while True:
            line = handle.readline()
            if line:
                yield line
            else:
                time.sleep(0.2)


if __name__ == "__main__":
    log_path = Path("/var/log/auth.log")
    for line in follow(log_path):
        print(line.strip())

Watchdog Event Handler

#!/usr/bin/env python3
"""
Use watchdog to monitor log directory and parse new files.
"""
from __future__ import annotations

import time
from pathlib import Path
from typing import List

from watchdog.events import FileSystemEventHandler
from watchdog.observers import Observer

from log_normalizer import normalize_line


class LogEventHandler(FileSystemEventHandler):
    """
    Process log file changes and emit normalized events.
    """

    def __init__(self, watch_paths: List[Path]) -> None:
        self.watch_paths = watch_paths

    def on_modified(self, event) -> None:
        if event.is_directory:
            return
        path = Path(event.src_path)
        if path.suffix not in {".log", ".txt"}:
            return
        self._handle_file(path)

    def _handle_file(self, path: Path) -> None:
        try:
            with path.open("r", encoding="utf-8") as handle:
                for line in handle.readlines()[-20:]:
                    normalized = normalize_line(line)
                    if normalized:
                        print(normalized)
        except OSError as exc:
            print(f"[!] Failed to read {path}: {exc}")


def main() -> None:
    watch_dir = Path("/var/log")
    handler = LogEventHandler([watch_dir])
    observer = Observer()
    observer.schedule(handler, str(watch_dir), recursive=False)

    observer.start()
    print("[*] Watching /var/log for updates...")
    try:
        while True:
            time.sleep(1)
    except KeyboardInterrupt:
        observer.stop()
    observer.join()


if __name__ == "__main__":
    main()

Rule-Based Correlation

Simple correlation rules can reduce alert fatigue by combining multiple signals into a single alert.

#!/usr/bin/env python3
"""
Rule-based correlation engine for normalized events.
"""
from __future__ import annotations

from collections import defaultdict
from datetime import datetime, timedelta
from typing import Dict, List


class RuleEngine:
    """
    Correlate events into security alerts.
    """

    def __init__(self, window_minutes: int = 10) -> None:
        self.window = timedelta(minutes=window_minutes)
        self.events_by_ip: Dict[str, List[Dict[str, str]]] = defaultdict(list)

    def add_event(self, event: Dict[str, str]) -> List[Dict[str, str]]:
        """
        Add event and return any triggered alerts.
        """
        alerts = []
        ip = event.get("source_ip", "unknown")
        now = datetime.utcnow()
        self.events_by_ip[ip].append(event)

        # Drop old events
        self.events_by_ip[ip] = [
            e for e in self.events_by_ip[ip]
            if now - datetime.fromisoformat(e.get("timestamp", now.isoformat())) <= self.window
        ]

        failed = [e for e in self.events_by_ip[ip] if "Failed password" in e.get("message", "")]
        if len(failed) >= 5:
            alerts.append({
                "alert_type": "correlated_bruteforce",
                "severity": "high",
                "source_ip": ip,
                "count": str(len(failed)),
                "message": "Correlated brute-force pattern detected",
                "timestamp": now.isoformat(),
            })

        return alerts


if __name__ == "__main__":
    engine = RuleEngine()
    sample = {
        "timestamp": datetime.utcnow().isoformat(),
        "source_ip": "203.0.113.12",
        "message": "Failed password for root",
    }
    print(engine.add_event(sample))

Section 4: Threat Intelligence & Geo Enrichment

Why Enrichment?

Alert quality improves when analysts can quickly see context: IP reputation, country, ASN, and known malicious indicators.

GeoIP Enrichment (geoip2)

#!/usr/bin/env python3
"""
Enrich log events with GeoIP data.
Requires GeoLite2 database (MaxMind) and geoip2 library.
"""
from __future__ import annotations

from dataclasses import dataclass
from typing import Dict, Optional

import geoip2.database

@dataclass
class GeoContext:
    ip: str
    country: str
    city: str
    latitude: float
    longitude: float


def lookup_geo(ip: str, db_path: str = "./GeoLite2-City.mmdb") -> Optional[GeoContext]:
    """
    Lookup IP geolocation safely.
    """
    try:
        reader = geoip2.database.Reader(db_path)
        response = reader.city(ip)
        return GeoContext(
            ip=ip,
            country=response.country.name or "Unknown",
            city=response.city.name or "Unknown",
            latitude=response.location.latitude or 0.0,
            longitude=response.location.longitude or 0.0,
        )
    except Exception as exc:
        print(f"[!] Geo lookup failed for {ip}: {exc}")
        return None


if __name__ == "__main__":
    ctx = lookup_geo("8.8.8.8")
    print(ctx)

Threat Intel Enrichment (AbuseIPDB/VirusTotal)

#!/usr/bin/env python3
"""
Threat intelligence enrichment for suspicious IPs.
Uses AbuseIPDB as an example (replace with your API provider).
"""
from __future__ import annotations

import os
import time
from typing import Dict, Optional

import requests

ABUSEIPDB_URL = "https://api.abuseipdb.com/api/v2/check"


def lookup_abuse_ip(ip: str, api_key: str) -> Optional[Dict[str, str]]:
    """
    Query AbuseIPDB for an IP reputation score.
    """
    headers = {"Key": api_key, "Accept": "application/json"}
    params = {"ipAddress": ip, "maxAgeInDays": 90}

    try:
        response = requests.get(ABUSEIPDB_URL, headers=headers, params=params, timeout=15)
        response.raise_for_status()
    except requests.RequestException as exc:
        print(f"[!] Threat intel lookup failed: {exc}")
        return None

    data = response.json().get("data", {})
    return {
        "ip": ip,
        "abuseConfidenceScore": str(data.get("abuseConfidenceScore", "0")),
        "isPublic": str(data.get("isPublic", "false")),
        "lastReportedAt": str(data.get("lastReportedAt", "")),
    }


def rate_limited_lookup(ip: str, api_key: str, delay: float = 1.2) -> Optional[Dict[str, str]]:
    """
    Respect API rate limits by sleeping between calls.
    """
    result = lookup_abuse_ip(ip, api_key)
    time.sleep(delay)
    return result


if __name__ == "__main__":
    key = os.getenv("ABUSEIPDB_KEY", "")
    if not key:
        raise SystemExit("Missing ABUSEIPDB_KEY")

    print(rate_limited_lookup("203.0.113.12", key))

Section 5: Alerting Pipeline

From Event to Alert

A defensive pipeline converts raw logs into alert objects. These alerts can be sent to Slack, email, or a ticketing system.

Simple Alert Formatter

#!/usr/bin/env python3
"""
Create alert objects for suspicious events.
"""
from __future__ import annotations

import json
from dataclasses import dataclass
from datetime import datetime
from typing import Dict

@dataclass
class Alert:
    alert_type: str
    severity: str
    message: str
    source_ip: str
    host: str
    timestamp: str

    def to_dict(self) -> Dict[str, str]:
        """Convert to dict for JSON export."""
        return {
            "alert_type": self.alert_type,
            "severity": self.severity,
            "message": self.message,
            "source_ip": self.source_ip,
            "host": self.host,
            "timestamp": self.timestamp,
        }


def build_alert(event: Dict[str, str], reason: str, severity: str = "high") -> Alert:
    """
    Build a structured alert from a normalized event.
    """
    return Alert(
        alert_type="suspicious_activity",
        severity=severity,
        message=reason,
        source_ip=event.get("source_ip", "unknown"),
        host=event.get("host", "unknown"),
        timestamp=event.get("timestamp", datetime.utcnow().isoformat()),
    )


def export_alert(alert: Alert, output_path: str) -> None:
    """
    Save alert to JSON for SIEM ingestion.
    """
    with open(output_path, "w", encoding="utf-8") as handle:
        json.dump(alert.to_dict(), handle, indent=2)


if __name__ == "__main__":
    test_event = {
        "timestamp": "2024-10-17T12:14:01Z",
        "host": "auth-01",
        "source_ip": "203.0.113.12",
        "message": "Failed password for admin",
    }
    alert = build_alert(test_event, reason="Brute force spike from IP")
    export_alert(alert, "./alert.json")

Slack Webhook Notifier

#!/usr/bin/env python3
"""
Send alerts to Slack via incoming webhook.
"""
from __future__ import annotations

import json
import os
from typing import Dict

import requests


def send_slack_alert(alert: Dict[str, str], webhook_url: str) -> bool:
    """
    Send alert to Slack channel.
    """
    payload = {
        "text": f"[{alert['severity'].upper()}] {alert['message']}\n"
                f"Host: {alert['host']} IP: {alert['source_ip']}\n"
                f"Time: {alert['timestamp']}"
    }

    try:
        response = requests.post(webhook_url, json=payload, timeout=10)
        response.raise_for_status()
        return True
    except requests.RequestException as exc:
        print(f"[!] Slack alert failed: {exc}")
        return False


if __name__ == "__main__":
    webhook = os.getenv("SLACK_WEBHOOK", "")
    if not webhook:
        raise SystemExit("Missing SLACK_WEBHOOK")

    sample_alert = {
        "severity": "high",
        "message": "Multiple failed logins detected",
        "host": "auth-01",
        "source_ip": "203.0.113.12",
        "timestamp": "2024-10-17T12:15:00Z",
    }
    send_slack_alert(sample_alert, webhook)

Section 6: Mini-SIEM Dashboard

Analyst-Friendly Summary

A mini dashboard turns alerts into a quick situational report. Start with aggregated counts and high-severity highlights.

Console Dashboard Output

#!/usr/bin/env python3
"""
Generate a console dashboard from alert JSON files.
"""
from __future__ import annotations

import glob
import json
from collections import Counter
from typing import Dict, List


def load_alerts(path_pattern: str = "./alerts/*.json") -> List[Dict[str, str]]:
    """
    Load alert files into memory.
    """
    alerts = []
    for path in glob.glob(path_pattern):
        try:
            with open(path, "r", encoding="utf-8") as handle:
                alerts.append(json.load(handle))
        except (OSError, json.JSONDecodeError) as exc:
            print(f"[!] Skipping {path}: {exc}")
    return alerts


def summarize_alerts(alerts: List[Dict[str, str]]) -> None:
    """
    Print summary table.
    """
    if not alerts:
        print("[✓] No alerts to summarize")
        return

    severity_counts = Counter(a.get("severity", "unknown") for a in alerts)
    type_counts = Counter(a.get("alert_type", "unknown") for a in alerts)

    print("=== ALERT SUMMARY ===")
    print("Severity counts:")
    for sev, count in severity_counts.items():
        print(f"  - {sev}: {count}")

    print("\nAlert types:")
    for alert_type, count in type_counts.items():
        print(f"  - {alert_type}: {count}")

    print("\nTop sources:")
    ip_counts = Counter(a.get("source_ip", "unknown") for a in alerts)
    for ip, count in ip_counts.most_common(5):
        print(f"  - {ip}: {count} alerts")


def main() -> None:
    """Entrypoint."""
    alerts = load_alerts()
    summarize_alerts(alerts)


if __name__ == "__main__":
    main()

Quick Visualization with Matplotlib

#!/usr/bin/env python3
"""
Plot alert trends for quick analyst visualization.
"""
from __future__ import annotations

import json
from pathlib import Path
from typing import Dict, List

import matplotlib.pyplot as plt
import pandas as pd


def load_alerts_from_dir(alert_dir: str = "./alerts") -> List[Dict[str, str]]:
    """
    Load alerts from a directory.
    """
    alerts = []
    for path in Path(alert_dir).glob("*.json"):
        try:
            alerts.append(json.loads(path.read_text()))
        except (OSError, json.JSONDecodeError) as exc:
            print(f"[!] Failed to read {path}: {exc}")
    return alerts


def plot_alerts(alerts: List[Dict[str, str]]) -> None:
    """
    Plot alerts by hour and severity.
    """
    if not alerts:
        print("[✓] No alert data to plot")
        return

    df = pd.DataFrame(alerts)
    df["timestamp"] = pd.to_datetime(df["timestamp"], errors="coerce")
    df = df.dropna(subset=["timestamp"])
    df["hour"] = df["timestamp"].dt.floor("H")

    counts = df.groupby(["hour", "severity"]).size().reset_index(name="count")

    for severity in counts["severity"].unique():
        subset = counts[counts["severity"] == severity]
        plt.plot(subset["hour"], subset["count"], marker="o", label=severity)

    plt.title("Alerts by Hour")
    plt.xlabel("Hour")
    plt.ylabel("Alert Count")
    plt.legend()
    plt.tight_layout()
    plt.savefig("alert_trends.png")
    print("[*] Saved chart to alert_trends.png")


if __name__ == "__main__":
    alert_list = load_alerts_from_dir()
    plot_alerts(alert_list)

Section 7: SIEM Integration Concepts

Mapping to a Common Schema

SIEM platforms rely on consistent fields. Map your normalized events to a schema like Elastic Common Schema (ECS) or Splunk CIM.

ECS Mapping Example

#!/usr/bin/env python3
"""
Convert normalized events to ECS-like schema for SIEM ingestion.
"""
from __future__ import annotations

from typing import Dict


def to_ecs(event: Dict[str, str]) -> Dict[str, str]:
    """
    Map normalized event to ECS-style fields.
    """
    return {
        "@timestamp": event.get("timestamp", ""),
        "host.name": event.get("host", ""),
        "event.dataset": event.get("source", ""),
        "process.name": event.get("app", ""),
        "source.ip": event.get("source_ip", ""),
        "user.name": event.get("username", ""),
        "message": event.get("message", ""),
        "event.kind": "event",
        "event.category": "authentication",
        "event.type": "info",
    }


if __name__ == "__main__":
    sample = {
        "timestamp": "2024-10-17T12:10:22Z",
        "host": "auth-01",
        "source": "syslog",
        "app": "sshd",
        "source_ip": "203.0.113.12",
        "username": "root",
        "message": "Failed password for root",
    }
    print(to_ecs(sample))

Elasticsearch Bulk Export (Offline)

#!/usr/bin/env python3
"""
Prepare bulk ingestion payload for Elasticsearch.
This outputs NDJSON for a local lab SIEM instance.
"""
from __future__ import annotations

import json
from typing import Dict, List


def bulk_format(events: List[Dict[str, str]], index_name: str) -> str:
    """
    Format events for ES bulk API.
    """
    lines = []
    for event in events:
        action = {"index": {"_index": index_name}}
        lines.append(json.dumps(action))
        lines.append(json.dumps(event))
    return "\\n".join(lines) + "\\n"


if __name__ == "__main__":
    events = [
        {"@timestamp": "2024-10-17T12:10:22Z", "message": "Failed password", "source.ip": "203.0.113.12"},
        {"@timestamp": "2024-10-17T12:11:22Z", "message": "Accepted password", "source.ip": "203.0.113.12"},
    ]
    payload = bulk_format(events, index_name="csy105-logs")
    with open("bulk.ndjson", "w", encoding="utf-8") as handle:
        handle.write(payload)
    print("[*] Wrote bulk payload to bulk.ndjson")

Response Playbook Stubs

Automated response should be conservative. Use playbooks to guide analysts rather than immediate destructive action.

#!/usr/bin/env python3
"""
Generate a response playbook entry for suspicious activity.
"""
from __future__ import annotations

from dataclasses import dataclass
from typing import Dict


@dataclass
class Playbook:
    title: str
    severity: str
    steps: str

    def to_dict(self) -> Dict[str, str]:
        return {
            "title": self.title,
            "severity": self.severity,
            "steps": self.steps,
        }


def create_playbook(alert: Dict[str, str]) -> Playbook:
    """
    Build a playbook entry for SOC analysts.
    """
    steps = (
        "1) Verify alert accuracy\\n"
        "2) Check source IP reputation\\n"
        "3) Search for related events\\n"
        "4) Notify incident response lead\\n"
        "5) Consider temporary block if malicious\\n"
    )
    return Playbook(
        title=f"Investigate: {alert.get('message', 'Suspicious event')}",
        severity=alert.get("severity", "medium"),
        steps=steps,
    )


if __name__ == "__main__":
    sample_alert = {"message": "Brute force spike from 203.0.113.12", "severity": "high"}
    print(create_playbook(sample_alert).to_dict())

Log Redaction Utility

#!/usr/bin/env python3
"""
Redact sensitive fields before sharing logs.
"""
from __future__ import annotations

import re
from typing import Dict


EMAIL_PATTERN = re.compile(r"[A-Za-z0-9._%+-]+@[A-Za-z0-9.-]+\\.[A-Za-z]{2,}")
IP_PATTERN = re.compile(r"\\b(?:\\d{1,3}\\.){3}\\d{1,3}\\b")


def redact_message(message: str) -> str:
    """
    Replace emails and IP addresses with placeholders.
    """
    message = EMAIL_PATTERN.sub("[REDACTED_EMAIL]", message)
    message = IP_PATTERN.sub("[REDACTED_IP]", message)
    return message


def redact_event(event: Dict[str, str]) -> Dict[str, str]:
    """
    Return a redacted copy of an event.
    """
    redacted = dict(event)
    redacted["message"] = redact_message(event.get("message", ""))
    if "source_ip" in redacted:
        redacted["source_ip"] = "[REDACTED_IP]"
    if "username" in redacted and redacted["username"]:
        redacted["username"] = "[REDACTED_USER]"
    return redacted


if __name__ == "__main__":
    sample = {
        "message": "Failed login for alice@example.com from 203.0.113.12",
        "source_ip": "203.0.113.12",
        "username": "alice",
    }
    print(redact_event(sample))

Ticketing Stub (Local)

#!/usr/bin/env python3
"""
Create a simple incident ticket in JSON for tracking.
"""
from __future__ import annotations

import json
from datetime import datetime
from typing import Dict


def create_ticket(alert: Dict[str, str], output_dir: str = "./tickets") -> str:
    """
    Write a ticket file to disk.
    """
    timestamp = datetime.utcnow().strftime("%Y%m%d_%H%M%S")
    ticket_id = f"TICKET-{timestamp}"
    ticket = {
        "id": ticket_id,
        "created_at": datetime.utcnow().isoformat(),
        "severity": alert.get("severity", "medium"),
        "summary": alert.get("message", "Suspicious activity"),
        "source_ip": alert.get("source_ip", "unknown"),
        "status": "open",
        "owner": "soc-analyst",
    }

    path = f"{output_dir}/{ticket_id}.json"
    with open(path, "w", encoding="utf-8") as handle:
        json.dump(ticket, handle, indent=2)
    return path


if __name__ == "__main__":
    sample_alert = {
        "severity": "high",
        "message": "Brute force spike from 203.0.113.12",
        "source_ip": "203.0.113.12",
    }
    print(create_ticket(sample_alert))

Lab 08: Defensive Log Analysis Toolkit (90-150 minutes)

Lab Overview

You will build a four-part defensive toolkit: multi-format ingestion, brute-force detection, geolocation anomalies, and threat intel enrichment.

Lab Part 1: Multi-format Log Aggregator (25-35 min)

Objective: Normalize syslog, JSON, and Windows Event logs into a single CSV.

Requirements:

• Accept a directory of log files and detect format
• Normalize to fields: timestamp, host, source, app, message, source_ip, username
• Write output to normalized_events.csv

Success Criteria: Running your script produces a clean CSV with consistent columns.

def extract_source_ip(message: str) -> str:
    """Extract IP from message; return empty if not found."""
    match = re.search(r"\b(?:\d{1,3}\.){3}\d{1,3}\b", message)
    return match.group(0) if match else ""

# Apply extraction after normalization
row["source_ip"] = extract_source_ip(row["message"])

Lab Part 2: Brute Force Attack Detector (20-30 min)

Objective: Detect brute-force logins using rolling windows.

Requirements:

• Detect 10+ failed logins for the same user within 15 minutes
• Output alerts to alerts/failed_login_*.json
• Include severity and remediation hint in each alert

Success Criteria: Trigger alerts with a provided test dataset.

failures = df[df["outcome"] == "failed"].set_index("timestamp")
windowed = failures.groupby("username").resample("15min").size()
spikes = windowed[windowed >= 10].reset_index(name="failed_count")

Lab Part 3: Geolocation-based Anomaly Detector (20-30 min)

Objective: Flag logins from unusual countries for high-value accounts.

Requirements:

• Use GeoIP data to tag each login event
• Build baseline country list per user (top 3 countries)
• Alert when a login appears from a new country

Success Criteria: Alerts include country, city, and user baseline.

baseline = (
    df.groupby(["username", "country"]).size()
      .reset_index(name="count")
      .sort_values(["username", "count"], ascending=[True, False])
)
# Keep top 3 countries per user
baseline = baseline.groupby("username").head(3)

Lab Part 4: Threat Intel Enrichment (20-30 min)

Objective: Enrich suspicious IPs with threat intelligence.

Requirements:

• Use AbuseIPDB or VirusTotal API
• Cache responses to avoid rate limits
• Attach score to alert JSON output

Success Criteria: Alerts include score and last-seen metadata.

cache = load_cache()
if cached := get_cached_ip(cache, ip):
    intel = cached
else:
    intel = lookup_abuse_ip(ip, api_key)
    if intel:
        set_cached_ip(cache, ip, intel)
        save_cache(cache)

Stretch Challenges (Optional)

• Build a correlation rule that links failed logins + new country + high abuse score
• Export alerts to CSV and include a one-page executive summary
• Create a daily summary job using cron and email the report to yourself

def correlated_alert(event: dict, geo: dict, intel: dict) -> dict | None:
    \"\"\"Return an alert only if multiple risk signals are present.\"\"\"
    if event.get(\"outcome\") != \"failed\":
        return None
    if geo.get(\"country\") in {\"Unknown\", \"\"}:
        return None
    if int(intel.get(\"abuseConfidenceScore\", 0)) < 50:
        return None

    return {
        \"alert_type\": \"multi_signal_bruteforce\",
        \"severity\": \"critical\",
        \"message\": \"Failed login from high-risk IP + unusual country\",
        \"source_ip\": event.get(\"source_ip\", \"unknown\"),
        \"country\": geo.get(\"country\", \"unknown\"),
        \"abuseScore\": intel.get(\"abuseConfidenceScore\", \"0\"),
    }

Additional Resources

Log Analysis

• Elastic Common Schema (ECS)
• rsyslog Documentation
• Windows Audit Policy

Threat Intelligence

• AbuseIPDB API
• VirusTotal API
• MaxMind GeoIP Databases

Blue Team Guides

• Blue Team Field Manual (BTFM)
• MITRE ATT&CK - Detection Analytics
• Practical Packet Analysis - for log-to-network correlation

Key Takeaways

• ✅ Normalization is the foundation of log analytics
• ✅ Baselines enable anomaly detection with minimal false positives
• ✅ Enrichment adds actionable context for analysts
• ✅ Alerting pipelines should be structured and rate-limited
• ✅ Mini-SIEM dashboards provide fast situational awareness
• ✅ Defensive automation reduces triage time and burnout

Week 08 Quiz

Test your understanding of defensive Python and log analysis.

Format: 10 multiple-choice questions. Passing score: 70%. Time: Untimed.
